SATURN-12

Since its introduction, Samson’s 12-strand working line, Saturn-12, has proven to be one of the longest lasting, most durable marine ropes available, increasing residual strength as much as 15-20% when compared with other HMPE lines and their conventional coatings. Its proprietary coating improves abrasion resistance and has been enhanced for greater UV resistance. Saturn-12 is made with Dyneema® SK78 fiber, which provides improved service life in applications where creep results from long-term static loads. This torque-free, flexible, and easy-to-handle construction is easy to inspect and splice in the field.

Product Code

882

Specific Gravity

.98

Elastic Elongation
10% 20% 30%
0.46% 0.70% 0.96%

Fiber (Core/cover)

HMPE

Splice

Modified Tuck Bury Class II

Mooring and Towing Lines

A size-for-size strength replacement for wire rope at only 1/7th the weight   •   Decreased coefficient of friction at winch surfaces   •   Easy to handle   •   Easy to inspect   •   Easy to splice   •   Flexible   •   Floats   •   Improved performance over standard HMPE ropes   •   Low creep   •   Proprietary coating increases residual strength as much as 15-20%   •   Proprietary coating reduces internal yarn to yarn abrasion   •   UV resistant

  Imperial Metric ISO
  DIAM.
inch
CIRC.
inch
WEIGHT PER 100 FT.
lbs
AVG. STRENGTH
lbs
MIN. STRENGTH
lbs
DIAM.
mm
CIRC.
mm
WEIGHT PER 100 M
kg
AVG. STRENGTH
kg
MIN. STRENGTH
kg
ISO 2307 STRENGTH
metric tons

  1/4 3/4 1.6 8,600 7,700 6 18 2.4 3,900 3,500 3.9
  5/16 1 2.7 13,700 12,300 8 24 4 6,200 5,600 6.2
  3/8 1 1/8 3.4 19,600 17,600 9 27 5.1 8,900 8,000 8.9
  7/16 1 1/4 4.2 23,900 21,500 11 33 6.2 10,800 9,800 10.8
  1/2 1 1/2 5.9 34,000 30,600 12 36 8.8 15,400 13,900 15.4
  9/16 1 3/4 7.9 40,500 36,500 14 42 11.8 18,400 16,500 18.4
  5/8 2 10.2 52,800 47,500 16 48 15.2 24,000 21,600 24
  3/4 2 1/4 13.3 64,400 58,000 18 54 19.8 29,200 26,300 29.2
  13/16 2 1/2 17 82,000 73,800 20 60 25.3 37,200 33,500 37.2
  7/8 2 3/4 19.6 90,800 81,700 22 66 29.2 41,200 37,100 41.2
  1 3 21.8 109,000 98,100 24 72 32.4 49,400 44,500 49.4
  1 1/16 3 1/4 27.5 134,000 121,000 26 78 40.9 60,800 54,700 60.8
  1 1/8 3 1/2 31.9 148,000 133,000 28 84 47.5 67,100 60,400 67.1
  1 1/4 3 3/4 36.2 165,000 149,000 30 90 53.9 74,800 67,400 74.8
  1 5/16 4 41.8 185,000 167,000 32 96 62.2 84,000 75,600 84
  1 3/8 4 1/8 45 205,000 185,000 34 100 67 93,000 83,700 93
  1 1/2 4 1/2 51.7 228,000 205,000 36 108 76.9 103,000 93,100 103
  1 5/8 5 65.2 283,000 255,000 40 120 97 128,000 116,000 128
  1 3/4 5 1/2 78.4 335,000 302,000 44 132 117 152,000 137,000 152
  2 6 87 381,000 343,000 48 144 129 173,000 156,000 173
  2 1/16 6 1/4 95 418,000 376,000 50 150 141 190,000 171,000 190
  2 1/8 6 1/2 109 457,000 411,000 52 156 162 207,000 187,000 207
  2 1/4 7 116 537,000 483,000 56 168 173 244,000 219,000 244
  2 1/2 7 1/2 148 588,000 529,000 60 180 220 267,000 240,000 267
  2 5/8 8 167 662,000 596,000 64 192 248 300,000 270,000 300
  2 3/4 8 1/2 187 735,000 662,000 68 204 278 333,000 300,000 333
  3 9 206 832,000 749,000 72 216 307 377,000 340,000 377
  3 1/8 9 1/2 228 920,000 828,000 76 228 339 417,000 376,000 417
  3 1/4 10 240 1,007,000 906,000 80 240 357 457,000 411,000 457
  3 1/2 10 1/2 295 1,170,000 1,053,000 86 254 439 531,000 478,000 531

ISO strength specifications are for unspliced rope. All other strength specifications are for spliced rope.
